Here it is guys, the beast, the best of, the Sapphire Nitro+ RX 580 8GB Limited Edition mining peformance test and review.

First of all i must say that this is one of the best GPU i ever tested. It is STABLE, RUN COOL, BEST HASHRATE and is HUGE!!!

As my previous test for the PULSE version i did the same tests, same practice. I tested it with Ethereum + Decred, Siacoin, LBRY Credits and PascalCoin also Zcash (Equihash), Monero (CryptoNight) and Nicehash.

Stock performance, mining hashrate and power consumption!

sapphire nitro+ rx 580 8gb limited edition non oc gpuz and clocks 1

sapphire nitro+ rx 580 8gb limited edition non oc gpuz and clocks 2

sapphire nitro+ rx 580 8gb limited edition ethereum mining stock non oc 1

sapphire nitro+ rx 580 8gb limited edition ethereum mining stock power draw

sapphire nitro+ rx 580 8gb limited edition ethereum mining stock with oc 1

sapphire nitro+ rx 580 8gb limited edition ethereum mining stock with oc power draw

POWER CONSUMPTION FOR SYSTEM IS AROUND 50W AND 60W

Stock bios & clocks (silent bios version) NO OTHER MODIFICATIONS

1411/2000
22.5 Mh/s on Ethereum
GPU-Z 135w
From wall 180w

Stock bios with undervolt, underclock and highest memory clock (silent bios version)

1150/2250 -96mV
21.2 mh/s on Ethereum
GPU-Z 90w
From wall 125w

To receive the latest updates follow me on social media! 🙂

facebook

twitter

google

youtube

Let’s get started

Sapphire Nitro+ RX 580 8GB Limited Edition Mining Performance Review

Sapphire 11265-00-40G Radeon NITRO+ RX 580 8GB GDDR5 DUAL HDMI / DVI-D / DUAL DP with backplate LIMITED EDITION (UEFI) PCI-E Graphic Cards

List Price:$299.99

Price:$299.99

1 Tools and Software needed

Combined AMD Drivers (check here how to do it) 16.11.5 http://support.amd.com/en-us/kb-articles/Pages/Radeon-Software-Crimson-Edition-16.11.5-Release-Notes.aspx + 17.5.1 http://support.amd.com/en-us/kb-articles/Pages/Radeon-Software-Crimson-ReLive-Edition-17.5.1-Release-Notes.aspx
AMD/ATI Pixel Clock Patcher https://www.monitortests.com/forum/Thread-AMD-ATI-Pixel-Clock-Patcher
Sapphire Trixx http://www.sapphiretech.com/catapage_tech.asp?cataid=291&lang=eng
ATIFlash 2.74 https://www.techpowerup.com/download/ati-atiflash/
MSI Afterburner http://download.msi.com/uti_exe/vga/MSIAfterburnerSetup.zip
GPU-Z https://www.techpowerup.com/download/techpowerup-gpu-z/
Claymore’s Dual Ethereum AMD+NVIDIA GPU Miner v9.4 https://mega.nz/#F!O4YA2JgD!n2b4iSHQDruEsYUvTQP5_w
Claymore’s ZCash AMD GPU Miner v12.4 https://mega.nz/#F!P0ZjFDjC!Cmb-ZRqlbAnNrajRtp4zvA
Claymore’s CryptoNote GPU Miner v9.7 https://mega.co.nz/#F!e4JVEAIJ!l1iF4z10fMyJzY5-LnyC2A
NiceHash https://www.nicehash.com/

I know that Claymore released version 9.5 but the tests were made with 9.4 one 🙂

NOTE: I already did a similar tutorial for a RX 470 4GB and i will link some points there to avoid writing the same thing over and over again!

For this card the bios is already switched to NON OC version (HDMI SIDE), do this:

first start the pc with his default bios position (non oc, hdmi side)
once windows is booted switch jumer to the other side and restart the rig
now check the following steps

2 Backup OC BIOS

Point 2 from previous tutorial: click here

atiflash saving sapphire rx 470 default bios

3 Switch BIOS

Point 3 from previous tutorial: click here

Sapphire_NITRO__RX_470_OC_BIOS_LED_Switch

4 Backup “Silent” BIOS

Point 4 from previous tutorial: click here

Before to continue further, please share this 🙂 thanks!

5 Download BIOS

Important, this BIOS is for Hynix memory only! Check your memory with GPUz software

V1: https://mega.nz/#!VoxEVDSD!Z-k7hViPrA-O4Z66jhd89iWhBgSuL0aQxGGVK2Qbx28

sapphire nitro+ rx 580 8gb gpuz hynix 1

6 Flash BIOS with ATiflash

VERY IMPORTANT: Always extract ATIflash to C:/atiflash folder and place the ROM file that needs to be flashed in the same directory

Point 5 from previous tutorial: click here

atiflash starting as administrator

atiflash load bios image

atiflash your vbios was programmed succsessfully

atiflash restart for modifications

Here are my results with this BIOS rom

Ethereum Mining

Claymore’s Dual Ethereum AMD+NVIDIA GPU Miner v9.3 (Windows/Linux)

Download and extract Claymore miner https://mega.nz/#F!O4YA2JgD!n2b4iSHQDruEsYUvTQP5_w
Right click on start.bat fileand click “Edit“
Replace details with yours
save,close and run start.bat

Ethereum Only

MSI Afterburner 30.5 MH/s

Clocks 1130/2250
Core Voltage -96mV
GPU-Z 100w
From wall 160w

sapphire nitro+ rx 580 8gb limited edition ethereum mining msi overclock

sapphire nitro+ rx 580 8gb limited edition ethereum mining power draw

Claymore 30.050 Mh/s

Clocks 1200/2250
Voltage -cvddc 850 -mvddc 850
GPU-Z 73w
From wall 115w

sapphire nitro+ rx 580 8gb limited edition ethereum mining claymore settings

sapphire nitro+ rx 580 8gb limited edition ethereum mining claymore settings power draw

start.bat file for ethereum only with claymore clocks and voltage: EthDcrMiner64.exe -epool eu1.ethermine.org:4444 -ewal ETHEREUM_WALLET.WORKER_NAME -epsw x -tstop 85 -tt 65 -fanmin 60 -fanmax 100 -cclock 1200 -mclock 2250 -cvddc 850 -mvddc 850

Ethereum Dual Mining

For dual mining i used claymore to set the cloks and undervolt.

Ethereum 31.5 Mh/s – Decred 950 Mh/s

Claymore -cclock 1200 -mclock 2250
Voltage -cvddc 850 -mvddc 850
GPU-Z 96w
From wall 150w

sapphire nitro+ rx 580 8gb limited edition ethereum dual mining decred

sapphire nitro+ rx 580 8gb limited edition claymore monero mining msi clocks power draw

Ethereum 31.5 MH/s – Siacoin 600 Mh/s

Claymore -cclock 1200 -mclock 2150 -dcri 19
Voltage -cvddc 850 -mcvddc 850
GPU-Z 96w
From wall 150w

sapphire nitro+ rx 580 8gb limited edition ethereum dual mining siacoin

sapphire nitro+ rx 580 8gb limited edition ethereum dual mining siacoin power draw

Ethereum 31.5 MH/s – PascalCoin 380 Mh/s

Claymore -cclock 1200 -mclock 2250 -dcri 12
Voltage -cvddc 850 -mvddc 850
GPU-Z 96w
From wall 150w

sapphire nitro+ rx 580 8gb limited edition ethereum dual mining pascalcoin

sapphire nitro+ rx 580 8gb limited edition ethereum dual mining pascalcoin power draw

start.bat file for ethereum dual decred with claymore clocks and voltage: EthDcrMiner64.exe -epool eu1.ethermine.org:4444 -ewal ETHEREUM_WALLET.WORKER_NAME -epsw x -dpool dcr.suprnova.cc:3252 -dwal SUPRNOVA_USER.WORKER_NAME -dpsw WORKER_PASS -tstop 85 -tt 65 -fanmin 60 -fanmax 100 -cclock 1200 -mclock 2250 -cvddc 850 -mvddc 850 -dcri 30

start.bat file for ethereum dual siacoin with claymore clocks and voltage: EthDcrMiner64.exe -epool eu1.ethermine.org:4444 -ewal ETHEREUM_WALLET.WORKER_NAME -epsw x -dpool stratum+tcp://sia-eu1.nanopool.org:7777 -dwal SIA_WALLET.WORKER_NAME -dcoin sia -tstop 85 -tt 65 -fanmin 60 -fanmax 100 -cclock 1200 -mclock 2250 -cvddc 850 -mvddc 850 -dcri 19

start.bat file for ethereum dual pascalcoin with claymore clocks and voltage: EthDcrMiner64.exe -epool eu1.ethermine.org:4444 -ewal ETHEREUM_WALLET.WORKER_NAME -epsw x -dpool stratum+tcp://pasc-eu1.nanopool.org:15555 -dwal ID.WALLET.WORKER_NAME -dpsw x -dcoin pasc -tstop 85 -tt 65 -fanmin 60 -fanmax 100 -cclock 1200 -mclock 2250 -cvddc 850 -mvddc 850 -dcri 12

Before to continue further, please share this 🙂 thanks!

ZCash Mining

Claymore’s ZCash AMD GPU Miner v12.4 (Windows/Linux)

Download and extract Claymore miner https://mega.nz/#F!P0ZjFDjC!Cmb-ZRqlbAnNrajRtp4zvA
Right click on start.bat fileand click “Edit“
Replace details with yours
save,close and run start.bat

MSI Afterburner 285 H/s

Clocks 1200/2250
Core Voltage -96mV
GPU-Z 103w
From wall 160w

sapphire nitro+ rx 580 8gb limited edition claymore zcash mining

sapphire nitro+ rx 580 8gb limited edition claymore zcash mining power draw

Claymore 295 H/s

Claymore -cclock 1200 -mclock 2250
Voltage -cvddc 850 -mvddc 850
GPU-Z 66w
From wall 100w

sapphire nitro+ rx 580 8gb limited edition claymore settings zcash mining

sapphire nitro+ rx 580 8gb limited edition claymore settings zcash mining power draw

start.bat file for ZCash (ZEC): ZecMiner64.exe -zpool eu1-zcash.flypool.org:3333 -zwal ZCASH_WALLET.WORKER_NAME -zpsw x -tstop 85 -tt 65 -fanmin 60 -fanmax 100 -cclock 1200 -mclock 2250 -cvddc 850 -mvddc 850

Monero Mining

Claymore’s CryptoNote GPU Miner v9.7

Download and extract Claymore miner https://mega.co.nz/#F!e4JVEAIJ!l1iF4z10fMyJzY5-LnyC2A
Right click on start.bat fileand click “Edit“
Replace details with yours
save,close and run start.bat

MSI Afterburner 700 H/s

Clocks 1200/2250
Core Voltage -96mV
GPU-Z 97w
From wall 120w

sapphire nitro+ rx 580 8gb limited edition claymore monero mining msi clocks

sapphire nitro+ rx 580 8gb limited edition claymore monero mining msi clocks power draw

Claymore 720 H/s

Claymore -cclock 1200 -mclock 2250
Voltage -cvddc 850 -mvddc 850
GPU-Z 66w
From wall 90w

sapphire nitro+ rx 580 8gb limited edition claymore monero mining

sapphire nitro+ rx 580 8gb limited edition claymore monero mining power draw

start.bat file for Monero (XMR) with claymore clocks and voltage: NsGpuCNMiner.exe -o stratum+tcp://xmr-eu.dwarfpool.com:8050 -u ZCASH_WALLET.WORKER_NAME -p x -tstop 85 -tt 65 -fanmin 60 -fanmax 100 -cclock 1200 -mclock 2250 -cvddc 850 -mvddc 850
